SS ‘wy )

A. Front Right Turn Signal Light Lead
Connector

B. Right Outer Middle Fairing

e The left outer middle fairing removal
is the same as the right outer middle
fairing.

e Check the fuses.

e Connect the front right turn signal
light lead connector.

e Insert the bosses into the holes.

A. Front Right Turn Signal Light Lead
Connector

B. Bosses

C. Holes

D. Projection

E. Grommets

e Install the removed parts.
