3-14 FUEL SYSTEM (DFI)
DFI System
○Color Codes:
    BK: Black        GY: Gray          PU: Purple
    BL: Blue         LB: Light Blue     R: Red
    BR: Brown        LG: Light Green    V: Violet
    CH: Chocolate     O: Orange         W: White
    DG: Dark Green    P: Pink           Y: Yellow
     G: Green
