FUEL SYSTEM (DFI) 3-37
Warning Indicator Light (LED)
Yellow Engine Warning/Red Immobilizer Warning
Indicator Light (LED) Inspection
   Yellow Engine Warning Indicator Light (LED) [A]
   Red Immobilizer Warning Indicator Light (LED) [B]
○In this model, the above mentioned warning indicator
 lights (LED) go on or blink by the data sent from the ECU.
•Refer to the Meter Unit Inspection (see Meter Unit Inspec-
 tion(16-76)).

Warning Indicator (LED) Circuit

    1. Meter Unit
    2. Joint Connector (2)
    3. ECU
