FUEL SYSTEM (DFI) 3-59
Fuel Tank
Fuel Tank Installation
• Note
  -56)).
         the above WARNING (see Fuel Tank Removal(3

• Check    that the dampers [A], pads [B] and trim [C] are in
  place on the frame and fuel tank.
      4 mm (0.16 in.) [D]
      1  2 mm (0.04  0.08 in.) [E]
      60  65 mm (2.4  2.6 in.) [F]
      15  20 mm (0.59  0.79 in.) [G]
    If the dampers, pad and trim are damaged or deteriorated,
    replace them.
•   Run the hoses correctly (see Cable, Wire, and Hose Rout-
    ing section (18-2)).

• Remove     the vinyl bag on the pipe and fuel hose joint.
• If the joint lock
  Check    the joint lock for deformation and wear.
                     is deformed, replace the fuel hose with a
    new one.
•   Check that there are no flaws, burrs, and adhesion of
    foreign materials on the pipe [A].
•   Apply engine oil to the pipe.
