APPENDIX 18-7
Cable, Wire, and Hose Routing
                                             NOTE
 ○The routing on KLZ1000C is shown using the figure of KLZ1000D.
  A: KLZ1000C is not equipped these parts.

  1. Clamps (Hold the main harness to the upper fairing bracket as shown.)
  2. Left Switch Housing Lead
  3. Check that the left switch housing lead is not caught in the bracket.
  4. Fuse Box (1) (Install it to the upper fairing bracket.)
  5. Headlight Lead Connector (Install it to the upper fairing bracket.)
  6. Main Harness
  7. Outside Temperature Sensor
  8. Front Brake Hose (to Front Master Cylinder)
  9. Vehicle-down Sensor
 10. Horn Lead
 11. IMU
 12. Turn Signal Relay
 13. Fuse Box (2) (Install it to the upper fairing bracket.)
