APPENDIX 18-29
Cable, Wire, and Hose Routing
                                             NOTE
 ○The routing on KLZ1000C is shown using the figure of KLZ1000D.
  A: KLZ1000C is not equipped these parts.

  1. Rear Brake Pipe (to Rear Master Cylinder)
  2. Rear Brake Pipe (to Rear Caliper)
  3. Battery Positive (+) Cable
  4. Joint Connectors
  5. Battery Positive (+) Cable Connector
  6. Fuse Box (3)
  7. Battery
  8. Relay Box
  9. Relay Box Lead
 10. Battery Negative (–) Cable
 11. Fuel Pump Lead
 12. Starter Motor Cable
 13. Main Harness
 14. ECU Leads
 15. Fuel Hose
