APPENDIX 18-35
Cable, Wire, and Hose Routing
                                              NOTE
 ○The routing on KLZ1000C is shown using the figure of KLZ1000D.
  A: KLZ1000C is not equipped these parts.

  1. Battery Negative (–) Cable
  2. Do not interfere with the bracket, when passing the battery cable.
  3. Engine Subharness
  4. Starter Motor Cable
  5. Clamp (Hold the engine subharness.)
  6. Clamp (Hold the alternator lead.)
  7. Alternator Lead
  8. Run the fuel tank drain hose and engine subharness to the inside of the engine sprocket cover.
  9. Side Stand Switch Lead
 10. Fuel Tank Drain Hose
 11. Clamp (Hold the engine subharness.)
 12. Gear Position Sensor Lead Connector
 13. Clamp (Hold the side stand switch lead.)
