APPENDIX 18-37
Cable, Wire, and Hose Routing
  1. Engine Subharness
  2. Catch Tank
  3. Fuel Tank Breather Hose
  4. Run the fuel tank breather hose, fuel tank drain hose and engine subharness to the inside of
     the engine sprocket cover.
  5. Clamp (Hold the engine subharness.)
  6. Gear Position Sensor Lead Connector
  7. Clamp (Hold the side stand switch lead.)
  8. Fuel Tank Drain Hose
  9. Side Stand Switch Lead
 10. Clamp (Hold the alternator lead.)
 11. Clamp (Hold the engine subharness.)
 12. Starter Motor Cable
 13. Alternator Lead
