FUEL SYSTEM (DFI) 3-11
DFI System
  1. ECU
  2. Battery 12 V 8 Ah
  3. Front Wheel Rotation Sensor
  4. Rear Wheel Rotation Sensor
  5. ABS Hydraulic Unit
  6. Vehicle-down Sensor
  7. Pressure Regulator
  8. Fuel Pump
  9. Fuel Filter
 10. Intake Air Temperature Sensor
 11. Delivery Pipe Assy
 12. Fuel Injectors
 13. Water Temperature Sensor
 14. Stick Coils
 15. Oxygen Sensor
 16. Crankshaft Sensor
 17. Intake Air Pressure Sensor #1
 18. Intake Air Pressure Sensor #2
 19. Air Switching Valve
 20. Main Throttle Sensor
 21. Subthrottle Valve Actuator
 22. Subthrottle Sensor
 23. Air Flow
 24. Fuel Flow
