FUEL SYSTEM (DFI) 3-121
Throttle Grip and Cables
Free Play Inspection
• Refer  to the Throttle Control System Inspection in the Pe-
  riodic Maintenance chapter.
Free Play Adjustment
• Refer  to the Throttle Control System Inspection in the Pe-
  riodic Maintenance chapter.
Cable Installation
• Install the throttle cables in accordance with the Cable,
  Wire, and Hose Routing section in the Appendix chapter.
• Install the lower ends of the throttle cables in the throttle
  pulley on the throttle body assy after installing the upper
    ends of the throttle cables in the grip.
•   After installation, adjust each cable properly (see Throttle
    Control System Inspection in the Periodic Maintenance
    chapter).
                            WARNING
    Operation with incorrectly routed or improperly ad-
    justed cables could result in an unsafe riding con-
    dition. Be sure the cables are routed correctly and
    properly adjusted.

Cable Lubrication
• Refer to the Chassis Parts Lubrication in the Periodic
  Maintenance chapter.
