APPENDIX 17-31
Cable, Wire, and Hose Routing
  1. Clamp (Hold the rear wheel rotation sensor lead.)
  2. Rear Wheel Rotation Sensor Lead
  3. Clamps (Hold the rear brake hose (to rear caliper) and rear wheel rotation sensor lead at the
     white painted mark of the rear wheel rotation sensor lead.)
  4. Clamp (Hold the rear brake hose (to rear caliper) and rear wheel rotation sensor lead.)
  5. Rear Brake Fluid Reservoir Hose
  6. Rear Brake Hose (to Rear Caliper)
  7. Clamp (Hold the rear brake pipes.)
  8. Rear Brake Pipe (to Rear Caliper)
  9. Rear Brake Pipe (to Rear Master Cylinder)
 10. About 9°
 11. About 3°
 12. Rear Wheel Rotation Sensor
 13. About 0.4°
