APPENDIX 18-55
Cable, Wire, and Hose Routing
  1. Rear Wheel Rotation Sensor Lead
  2. Clamps (Hold the rear wheel rotation sensor lead.)
  3. Rear Brake Pipe (to Rear Master Cylinder)
  4. Rear Brake Pipe (to Rear Caliper)
  5. Clamp (Hold the rear brake hose (to rear caliper) and rear wheel rotation sensor lead to bracket.)
  6. Clamps (Hold the rear brake hose (to rear caliper) and rear wheel rotation sensor lead at the
     white painted mark of the rear wheel rotation sensor lead.)
  7. Rear Brake Hose (to Rear Caliper)
  8. Run the rear brake hose (to rear caliper) and rear wheel rotation sensor lead through the clamp.
  9. Clamp (Hold the rear brake hose (to rear caliper).)
 10. Rear Wheel Rotation Sensor
 11. Rear Brake Fluid Reservoir Hose
 12. About 93°
 13. About 99°
