3-72 FUEL SYSTEM (DFI)
Rear Wheel Rotation Sensor Signal (Service Code 24) (DTC P2158)
Wheel Rotation Sensor Circuit

  1. ECU
  2. Rear Wheel Rotation Sensor
  3. ABS Hydraulic Unit
  4. Front Wheel Rotation Sensor
